MSV01
E4
Description

For cranes operating in highway and off-the-road applications.
Features
  • Excellent traction in all haul road conditions
  • Deep tread grooves provide cooler running
    tread for high site TKPH/TMPH
  • E4+ extra-deep tread for longest tire life
  • Wide, square footprint distributes load for
    minimal haul road disturbance
  • Reinforced bead, shoulder and sidewall for
    increased cut resistance
  • Heat-resistant undertread reduces tire temperature
  • Multiple tread compound options target specific site requirements
Downloads

Applications

Size Rating Type Rim O.D. S.W. T.D. Infl. L.C.C. (lbs/kg) L.I.
  in
mm		 in
mm		 in
mm		 psi
kPa		 50 mph
80 kph
14.00R24 (385/95R24) *** TT 10.00 W 54.3
1379		 15.3
389		 29
23		 130
900		 13200
6000		 170F
14.00R25 (385/95R25) *** TL 9.50/1.7 CR 10.00/1.5 54.3
1379		 15.3
389		 29
23		 130
900		 13200
6000		 170F
16.00R25 (445/95R25) *** TL 11.00/1.7 CR 11.25/2.0 58.9
1495		 17.5
444		 33
26		 130
900		 14800
6700		 174F
20.5R25 (525/80R25) *** TL 17.00/1.7 CR 17.00/2.0 58.7
1490		 21.1
535		 38
30		 102
700		 16100
7300		 177F

* Applications with load requirements exceeding the published values must be reviewed and approved by Maxam Tire. Please contact your Maxam Tire representative for more details.
